Configuration name

description

Remarks

Laser power

RF  Germany Rofin SR151 250 W

Optional 180W, 350W

Dimensions

4000×2000×1300mm

Processing stroke

X: 1300, Y: 2500mm

MV3000 type 1500 × 3000mm

working desk

Triangular aluminum strip support

Alignment device

infrared

the fastest speed

20m/min

Fastest

Acrylic maximum cutting thickness

40mm

Perfect cutting

X/Y axis positioning accuracy

±0.05

Mm/m (mm/m)

X/Y axis repeat positioning accuracy

±0.05

Mm

Cutting head

Lens fast precision cutting head

Independent research and development

Focal length adjustment

electric

Mechanical transmission system

Ball screw for X/Y axis

Taiwan import

X/Y/Z uses TBI rail

Taiwan import

Dedicated cooling system

Temperature control accuracy of ±0.5 °C, a variety of alarm protection functions: compressor delay protection; compressor overcurrent protection; water flow alarm; temperature super high, ultra low alarm

Special domain

Optical path system

Flying light path, sealed and dustproof

Optical lens cooling system

Exhaust system

Intelligent partition to start the exhaust

sport control

Offline control

乐创LEETRO

Support software

CAD, Coredraw, etc.

server Driver

MITSUBISHI

Mitsubishi Japan

HMI

High resolution capacitive touch screen

FLEXEM

Fan control

Touch screen

Self-configuration
